Kyocera KM-4035

2FD/2FF/2FG
1-3-52
18. Remove 1 screw and take off the modular
cover.
Figure 1-3-121
19. Hang the modular cover onto the holes on the
controller-box cover, and fasten it into place
with 1 screw.
Screw
Modular cover
Screw
Holes
Modular cover
Figure 1-3-122
17. Fasten the shield cover into place with 13
screws.
Figure 1-3-123
Shield cover
Screws
