2KJ/2KH
1-5-14
7. Remove the screw and remove the upper
paper feed unit.
Figure 1-5-22
8. Remove the springs, stop ring and bush and
then remove the shaft holder from the upper
paper feed unit.
Figure 1-5-23
Screw
Upper paper feed unit
Upper paper feed unit
Stop ring
Bush
Spring
Spring
Shaft holder
