Kyocera TASKalfa 181 - Adjustment: Trailing Edge Margin Adjustment; Setting the Printing Area for Folio Paper

2KJ/2KH
1-3-14
U034
Adjustment: Trailing edge margin adjustment
1. Select [MGN REAR].
2. Press the interrupt key.
3. Press the start key to output a test pattern.
4. Change the setting value using the cursor left/right keys.
For output example, increase the value.
Figure 1-3-3
5. Press the start key. The value is set.
Completion
Press the stop/clear key. The screen for selecting a maintenance item No. is displayed.
U035
Setting the printing area for folio paper
Description
Changes the printing area for copying on folio paper.
Purpose
To prevent cropped images on the trailing edge or left/right side of copy paper by setting the actual printing
area for folio paper.
Setting
1. Press the start key.
2. Select the item to be set using the cursor up/down keys.
3. Change the setting using the cursor left/right keys.
4. Press the start key. The value is set.
Completion
Press the stop/clear key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Description Setting
range
Initial
setting
Change in
value per step
MGN REAR Trailing edge margin adjustment -4.0 to 10.0 2.0 0.1 ms
Correct image
Output
example
Trailing edge margin
Display Setting Setting range Initial setting
LENGTH DATA Length 330 to 356 mm 330
WIDTH DATA Width 200 to 220 mm 210
