2KJ/2KH
1-3-8
U019
Displaying the ROM version
Description
Displays the part number of the ROM fitted to each PWB.
Purpose
To check the part number or to decide, if the newest version of ROM is installed.
Method
1. Press the start key. The ROM version are displayed.
2. Change the screen using the cursor up/down keys.
Completion
Press the stop/clear key. The screen for selecting a maintenance item No. is displayed.
U020
Initializing all data
Description
Initializes all the backup RAM on the main PWB to return to the original settings.
Refer to *1 of the maintenance mode item list about the item initialized.
Reset each intialized mode based on an own-status report U000 printed at installing the machine.
Purpose
To be executed as required.
Method
1. Press the start key.
2. Select the [EXECUTE] using the cursor up/down keys.
3. Press the start key. All data in the backup memory is initialized and the default setting for the Japan
specifications is registered.
4. When initialization is complete, the machine automatically returns to the same status as when the main
power switch is turned on.
Maintenance
item No.
Description
Display Description
MAIN Main ROM
ENGINE Engine ROM
LANG(St) Standard language ROM
LANG(Op) Optional language ROM
MAIN BOOT Boot of main ROM
PRINTER Printer ROM
NWS Optional network scanner ROM
DP Optional DP ROM
FINISHER Optional built-in finisher ROM
CASS2 Optional first paper feeder ROM (standard for 22 ppm model)
CASS3 Optional second paper feeder ROM
CASS4 Optional third paper feeder ROM
