Kyocera TASKalfa 181 - Detaching and Refitting the Feed Roller (22 Ppm Model Only)

2KJ/2KH
1-5-9
(3) Detaching and refitting the feed roller (22 ppm model only)
Follow the procedure below to replace the feed roller.
Procedure
1. Remove the front left lower cover (see page
1-5-3).
2. Remove three cover labels.
3. Remove five screws and remove the main
body from paper feeder.
Figure 1-5-14
Screw
Cover label
Paper feeder
Cover label
Cover label
Screw
Screw
Screw
Screw
