2KJ/2KH
1-3-41
U202
Setting the KMAS host monitoring system
Description
Initializes or operates the KMAS host monitoring system.
This is an optional device which is currently supported only by Japanese specification machines, so no setting
is necessary.
U203
Checking DP operation
Description
Simulates the original conveying operation separately in the DP.
Purpose
To check the DP operation.
Method
1. Press the start key.
2. Place an original in the DP if running this simulation with paper.
3. Select the item to be operated using the cursor up/down keys.
4. Press the start key. The operation starts.
5. To stop continuous operation, press the stop/clear key.
Completion
Press the stop/clear key. The screen for selecting a maintenance item No. is displayed.
U204
Setting the presence or absence of a key card or key counter
Description
Sets the presence or absence of the optional key card or key counter.
Purpose
To run this maintenance item if a key card or key counter is installed.
Setting
1. Press the start key.
2. Select the optional counter to be installed using the cursor up/down keys.
3. Press the start key. The setting is set.
Completion
Press the stop/clear key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Operation
ADP With paper, single-sided original
RADP With paper, double-sided original
ADP (NON P) Without paper, single-sided original (continuous operation)
RADP (NON P) Without paper, double-sided original (continuous operation)
Display Description
OFF Not installed
KEY-CARD The key card is installed
KEY-COUNTER The key counter is installed
