15. NCU PWB (NCUPWB)
*2
............................... Controls connection to the telephone line.
16. Fax relay PWB (FRPWB)
*2
........................... Consists of wiring relay circuits between fax control PWB and main PWB.
*1: Option for 18 ppm model/standard for 22 ppm model
*2: Option
List of correspondences of PWB names
No. Name used in service manual Name used in parts list
1 Engine PWB (EPWB) PARTS PWB ENGINE ASSY SP
2 Main PWB (MPWB) PARTS PWB MAIN ASSY SP
3 Power source PWB (PSPWB) PARTS LVU100(M) SP / PARTS LVU200(M) SP
4 High voltage PWB (HVPWB) PARTS HVU SP
5 Inverter PWB (INPWB) PARTS LAMP INVERTER SP
6 CCD PWB (CCDPWB) -
7 Operation PWB (OPWB) PARTS PWB PANEL ASSY SP
8 LCD PWB (LCDPWB) PARTS LCD OPERATION SP
9 APC PWB (APCPWB) -
10 PD PWB (PDPWB) -
11 Cassette PWB (CPWB) PARTS PWB INTERFACE ASSY SP
12 Cassette main PWB (CMPWB) PARTS PWB PF MAIN ASSY SP
13 Cassette heater PWB (CHPWB) HEATER BRANCH PCB ASS'Y
14 Fax control PWB (FCPWB) PARTS MAIN FAX ASSY SP
15 NCU PWB (NCUPWB) NCU ASS'Y(N.A) / NCU ASS'Y(CTR)
16 Fax relay PWB (FRPWB) PARTS PWB MAIN-FAX-IF ASSY SP
