156 WM-OM-E Rev I

range Range

Definition:

Computes the difference between the value of the rightmost and that of the

leftmost populated bin.

Description:

The rightmost and leftmost populated bins are identified. The difference in value

between the two is returned as the range.

Example:

In this example, range is 2 mV.
