28 WM-OM-E Rev I
Clock Accuracy: </= 1 ppm at 0 to 50 °C (WavePro 7000A Series, DDA-3000A: </= 10 ppm at 0 to
40 °C)
Interpolator Resolution: 1.2 ps
External Timebase Clock: 100 MHz, 50 ohms impedance, applied at the rear input (10 MHz, 50
ohms for WavePro 7000A Series)
External Sample Clock: 30 MHz to 2 GHz max., 50 ohms impedance, applied at the Auxiliary
input (WavePro 7100A, DDA-3000A: 30 MHz to 1 GHz)
Acquisition System
Single-shot Sample Rate/Ch: 10 GS/s (WaveMaster 8620A: 20 GS/s)
Memory:
WaveMaster 8420A and 8620A:
Maximum Acquisition
Points/Ch
Standard 10M
VL Memory Option 32M
XL Memory Option 50M
WaveMaster 8400A XXL and 8600A XXL: 50 Mpts/Ch; 100 Mpts when using 4 or 2 Ch,
respectively
WavePro 7100A, 7200A, 7300A:
Maximum Acquisition
Points/Ch
4 Ch/2 Ch
Standard 10M/20M
VL Memory Option 16M/32M
XL Memory Option 24M/50M
WavePro 7100A, 7200A, 7300A XXL models: 50 Mpts/Ch; 100 Mpts when using 4 or 2 Ch,
respectively
