X-Stream Operator’s Manual
WM-OM-E Rev I 307
Debugging Scripts
Until we have integrated a more comprehensive debugger for VBScript there is a workaround.
1. Download the Windows Scripting Debugger for Windows 2000 from here:
http://download.microsoft.com/download/winscript56/Install/1.0a/NT45XP/EN-US/scd10e
n.exe
2. Enable JIT (Just In Time) debugging by setting the following registry key
HKCU\Software\Microsoft\Windows Script\Settings\JITDebug = to 1 (DWORD value)
3. Place a Stop statement in your script.
Now, when the Stop statement is executed the debugger will open and allow single-stepping,
variable examination, etc.
Using VBA or Visual Basic to debug VBScripts is not recommended since the language syntax for
these three variants of basic is slightly different.
Horizontal Control Variables
InResult.HorizontalOffset
Double precision
Time shift of input waveform on grid in units of
horizontal scale
OutResult.HorizontalOffset
Double precision
Time shift of output waveform on grid in units
of horizontal scale
InResult.HorizontalPerStep
Double precision
Time between successive samples in the input
waveform
OutResult.HorizontalPerStep
Double precision Time between successive samples in the
output waveform
InResult.HorizontalUnits
String Horizontal units of input waveform
OutResult.HorizontalUnits
String Horizontal units of output waveform
InResult.Samples
Integer Number of samples in input waveform
Vertical Control Variables
InResult.VerticalOffset
Double precision Vertical shift of input waveform on grid
OutResult.VerticalOffset
Double precision Vertical shift of output waveform on grid
InResult.VerticalPerStep
Double precision Difference between successive possible levels
in the input waveform memory
OutResultVerticalPerStep
Double precision Difference between successive possible levels
in the output waveform memory
1 / 65536 of vertical full scale
