36 WM-OM-E Rev I
Warranty and Service
3-year warranty; calibration recommended yearly
Optional service programs include extended warranty, upgrades, and calibration services.
Environmental Characteristics
Temperature
Operating: 5 to 40 °C
Storage (non-operating): -20 to +60 °C
Humidity
Operating: Maximum relative humidity 80% for temperatures up to 31 °C decreasing linearly to
50% relative humidity at 40 °C
Storage (non-operating): 5 to 95% RH (non-condensing) as tested per MIL-PRF-28800F
Altitude
Operating: Up to 2,000 m
Storage (non-operating): Up to 12,192 m (40,000 ft)
Random Vibration
Operating: 0.31 g
rms
, 5 Hz to 500 Hz, 15 minutes in each of 3 orthogonal axes
Non-operating: 2.4 g
rms
, 5 to 500 Hz, 15 minutes in each of 3 orthogonal axes
Shock
Functional Shock: 20 g peak, half sine, 11 ms pulse, 3 shocks (positive and negative) in each of 3
orthogonal axes, 18 shocks total
Certifications
CE Approved, UL and cUL Listed
CE Declaration of Conformity
The oscilloscope meets requirements of EMC Directive 89/336/EEC for Electromagnetic
Compatibility and Low Voltage Directive 73/23/EEC for Product Safety.
EMC Directive: EN 61326/A3:2003
EMC requirements for electrical equipment for measurement,
control, and laboratory use.
EN 55011/A2:2002, Class A Radiated and conducted emissions
(Class A)*
EN 61000-3-2/A2:2005 Harmonic Current Emissions (Class A)
Electromagnetic Emissions:
EN 61000-3-3/A2:2005 Voltage Fluctuations and Flickers
(Pst = 1)
* To conform to Radiated Emissions standard, use properly shielded cables on all I/O terminals.
