X-Stream Operator’s Manual
WM-OM-E Rev I 35
y Disk Drive Parameters:
amplitude symmetry
auto correlation s/n
local base
local baseline separation
local maximum
local minimum
local number
local peak-peak
local time between events
local time between peaks
local time between troughs
local time at minimum
local time at maximum
local time peak-trough
local time over threshold
local time trough-peak
local time under threshold
narrow band phase
narrow band power
non-linear transition shift
overwrite
pulse width 50
pulse width 50-
pulse width 50+
resolution
track average amplitude
track average amplitude-
track average amplitude+
y Correlation function
y Trend (datalog) of up to one million events
y Histograms expanded with 19 histogram parameters and up to 2 billion events
General
Auto Calibration: Ensures specified DC and timing accuracy is maintained for 1 year minimum.
Power Requirements:
On State:
WaveMaster 8620A, 8420
</= 800 watts (800 VA) depending on
accessories installed (internal printer, probes,
PC port plug-ins, etc.)
WaveMaster 8600A, 8500A, 8400A,
WavePro 7000A Series
DDA-5005A, 3000A
</= 650 watts (650 VA) depending on
accessories installed (internal printer, probes,
PC port plug-ins, etc.)
Standby State: 12 watts
Fuse: One 5x20 mm fuse (T10.0 A/250 V)
Battery Backup: Front panel settings retained for two years minimum
Physical Dimensions (HWD): 264 mm x 397 mm x 491 mm (10.4 in. x 15.6 in. x 19.3 in.); height
measurement excludes foot pads
Weight: 18 kg (39 lbs.)
Shipping Weight: 24 kg (53 lbs.)
