66 WM-OM-E Rev I
DDAScopes
On your front panel, the Default Setup push button does not exist. For these instruments, therefore,
to recall a default setup
1. Press the Save/Recall push button to the left of the Drive Analysis push button.
Note: You can also touch File in the menu bar, then Recall Setup... in the drop-down menu.
2. Touch the "Recall Setup" tab in the dialog.
3. Then touch the on-screen Recall Default button:
.
Adding a New Option
To add a software option you need a key code to enable the option. Call LeCroy Customer Support
to place an order and receive the code.
To add the software option do the following:
1. In the menu bar, touch
.
2. In the dialog area, touch the
tab.
3. Touch
.
4. Use the pop-up keyboard to type the key code. Touch O.K. on the keyboard to enter the
information.
5. The name of the feature you just installed is shown below the list of key codes. You can use
the scroll buttons to see the name of the option installed with each key code listed:
