X-Stream Operator’s Manual
WM-OM-E Rev I 27
Bandwidth Limiters:
• Full
• 4 GHz (WaveMaster 8600A, 8500A, DDA-5005A)
• 3 GHz (WaveMaster 8600A, 8500A, 8400A, 8420, DDA-5005A)
• 1 GHz (WaveMaster scopes, DDA-5005A)
• 200 MHz
• 20 MHz
Input Impedance: 50 ohms +/-2%; WavePro 7000A Series: 50 ohms +/-1.5%, 1 Mohms
Input Coupling: DC, GND; AC (WavePro 7000A Series)
Max Input Voltage
WaveMaster, DDA-5005A: +/-4 V peak; WavePro 7000A Series, DDA-3000A: 50 ohms: 5 Vrms, 1
Mohms: 100 Vmax (peak AC: 5 kHz + DC)
Installation (Overvoltage) Category: CAT I
Vertical Resolution: 8 bits; up to 11 bits with enhanced resolution (ERES)
Sensitivity: 2 mV to 1 V/div fully variable (WavePro 7000A Series: 1 Mohms: 2 mV to 2 V/div fully
variable)
DC Gain Accuracy: +/-1.5% of full scale
Offset Range: 2 mV to 194 mV/div: +/-750 mV; 195 mV to 1 V/div: +/-4 V (WaveMaster,
DDA-5005A)
DDA-3000A, WavePro 7000A Series:
50 ohms
+/-700 mV @ 2.0 to 4.99 mV/div
+/-1.5 V @ 5 to 100 mV/div
+/-10 V @ 0.102 to 1 V/div
1 Mohms
+/-700 mV @ 2.0 to 4.99 mV/div
+/-1.5 V @ 5 to 100 mV/div
+/-20 V @ 0.102 to 2 V/div
Offset Accuracy: +/-(1.5% of full scale value + 1.5% of offset value + 2 mV); WavePro 7000A
Series, DDA-3000A: +/-(1.5% of full scale value + 0.5% of offset value + 2 mV)
Horizontal System
Timebases: Internal timebase common to 4 input channels; an external clock can be applied at the
auxiliary input
Time/div Range: 20 ps/div to 1000 s/div (10 s/div in Auto trigger mode)
Math & Zoom Traces: 4 independent zoom and 4 math/zoom traces standard; 8 math/zoom
traces available with XMAP (Master Analysis Package) option
