32 WM-OM-E Rev I
Interface
Remote Control: Through Windows Automation or LeCroy Remote Command set, supports front
panel controls and internal functions via GPIB or Ethernet.
GPIB Port (optional): Supports IEEE-488.2
Ethernet Port: 10/100Base-T Ethernet interface
USB Ports: 4 USB ports support Windows compatible devices.
External Monitor Port (standard): 15-pin D-Type SVGA compatible
Parallel Port: 1 standard
Auxiliary Output
Signal Types: Select from calibrator or control signals output on front panel.
Calibrator Signal: 5 Hz to 5 MHz (1 MHz for WavePro 7000A Series, DDA-3000A) square wave or
DC level; 0.0 to 5.0 V (selectable) into 50 ohms (0 to 1 V into 1 Mohms), or TTL Volts
Control Signals: trigger enabled, trigger out, pass/fail status, square, DC level
Auxiliary Input
Signal Types: Select External Trigger input on front panel. 1X: 100 mV/div; 10X: 1 V/div; ÷10: 10
mV/div
Math Tools (standard)
Display up to four math function traces (F1 to F4). The easy-to-use graphical interface simplifies
setup of up to two operations on each function trace. Function traces can be chained together to
perform math-on-math.
absolute value
average (summed)
average (continuous)
derivative
deskew (resample)
difference ()
enhanced resolution (to 11 bits vertical)
envelope
exp (base e)
exp (base 10)
fft (basic)
floor
histogram of 1,000 events
integral
invert (negate)
ln (log base e)
log (base 10)
product (X)
ratio (/)
reciprocal
rescale (with units)
roof
segment
(sinX)/X
square
square root
sum (+)
trend (datalog) of 1,000 events
zoom (identity)
