X-Stream Operator’s Manual
WM-OM-E Rev I 61
y dialog area
Menu Bar
The top of the screen contains a toolbar of commonly used functions. Whenever you touch one of
these buttons, the dialog area at the bottom of the screen switches to show the setup for that
function.
Signal Display Grid
You can set up the signal display area by touching
in the toolbar, then the
tab. The display dialog offers a choice of grid combinations and a means to set the
grid intensity.
Dialog Area
The lower portion is where you make selections and input data. The dialog area is controlled by
both toolbar touch buttons and front panel push buttons. Similarities between functions are shown
in this Table of Equivalent Functions.
