54 WM-OM-E Rev I
Help Displays the on-line Help manual. You can choose to receive control help,
or to search for the information you need using the Table of Contents and
Index. Control Help displays help for a particular button, menu item, data
field, etc. contained in the dialogs.
Save/Recall Calls up the dialogs for saving and recalling waveforms and setups, and
for disk utilities.
Analog
Persist
Provides a three dimensional view of the signal: time, voltage, and a third
dimension related to the frequency of occurrence, as shown by a
color-graded (thermal) or intensity-graded display.
QuickZoom
Automatically displays magnified views of up to four signal inputs on
multiple grids. With four input signals, the signals are displayed along with
four zoom traces, each on its own grid. This button turns off all other
traces.
General Control
Buttons:
Print Screen
Prints the displayed screen to a file, a printer, the clipboard, or attaches it
as an e-mail. Select the device and format it in the Utilities Hardcopy
dialog.
Utilities
For setup of scope features including hardcopy devices and formats, date
and time, and remote control interfaces, etc.; or for checking status,
options, etc..
Touch Screen
(toggle switch)
Activates or deactivates the touch screen.
Clear Sweeps
Clears data from multiple sweeps (acquisitions) including: persistence
trace displays, averaged traces, parameter statistics, and Histicons.
During waveform readout, cancels readout.
STANDBY Lamp:
The STANDBY lamp indicates when the scope has placed itself in
standby mode. In this mode, current settings are retained.
