210 WM-OM-E Rev I
the time between adjacent falling
and rising edges. For both cases,
widths of all waveform pulses are
averaged for the final result.
Width@level Width measured at a specific level.
Time between two
transitions of opposite slope
at a specified level. (Slope
specified for 1st transition.)
Enhanced version sets
measurement calculations to
use one of the following:
Base & Top (% or absolute)
Peak-Peak (%)
0V-Max (%)
0V-Min (%)
Reference levels and
edge-transition polarity
can be selected.
Hysteresis argument
used to discriminate
levels from noise in
data.
Available with JTA2,
USB2, EMC, SDA, and
XMAP options.
Standard in SDA100G
and WavePro 7000A
scopes.
Enhanced parameter
available with EMC
option.
WidthN Width measured at the 50% level
and negative slope.
Standard parameter.
X@max Determines the horizontal axis
location of the maximum value
between the cursors.
Restricted to time and
frequency waveforms
only.
X@min Determines the horizontal axis
location of the minimum value
between the cursors.
Restricted to time and
frequency waveforms
only.
Zero Level Zero level of an eye diagram Available with SDA and
SDM options.
Standard in SDA,
SDA100G, and
WaveExpert scopes.
