Figure 146. Removing screws from the processor board
Screw Quantity
Tools
1
4 PH2 screwdriver
2
6 PH2 screwdriver
3
2 Hex wrench
Step 5. Remove the following components from the processor board.
• Cable wall brackets
Figure 147. Removing components from the processor board
Step 6. Separate the processor board from the supporting sheet metal.
232
ThinkSystem SR655 V3 User Guide
