Lenze 8200 vector series Mounting Instructions

Mechanical installation
Standard devices in the power range 75 ... 90 kW
Mounting with fixing brackets (standard)
4

136
EDK82EV903 DE/EN/FR 5.1
Controller variant "3xx" (with fully mounted footprint filter)
For this mounting variant you require controller type E82EVxxxK4B3xx.
2
3
1
m
g
³ 150 mm
a
b1
k
³ 100 mm
c
d1
d2
d
b
l
e
e
f
g
a
L
M 8
max. 15 mm
c1
0
³ 50 mm
³ 50 mm
M 8
18 Nm
159.3 lb-in
8200vec283

Loosen both screws to be able to remove the housing cover. The assembly kit is located under
the housing cover.

Installation of mounting angles

Dimensions

Arrange the controllers side by side with spacing to be able to disassemble the eyebolts.
Dimensions [mm]
8200 vector integr. mains
filter
2)
a b b1 c c1 d d1 d2 e
1)
g k m
E82EV553K4B3xx E82ZN75334B230
450 802 680 393 28.5 750 38 702 375 11 28 18
E82EV553K4B3xx E82ZN90334B230
1)
If the function module is attached: observe mounting clearance and cable bending radius. The terminals of function
modules in PT design protrude above the housing by 8 mm.
2)
The integrated mains filters are only designed for controller operation at rated power. Different filters with different
dimensions are possible (
 140).
