Lenze 8200 vector series Mounting Instructions

Commissioning
Important codes for quick commissioning
7
 180
EDK82EV903 DE/EN/FR 5.1
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0010
uSEr
Minimum
output
frequency
0.00 0.00
à 14.5 Hz
{0.02 Hz} 650.00
l C0010 not effective in the case of
bipolar setpoint selection (−10 V ...
+ 10 V)
l C0010 only limits the analog input
1
l In the case of a max. output
frequency > 50 Hz the switching
threshold of the auto DCB in C0019
has to be increased.
l From software 3.5: If
C0010 > C0011, the drive does not
start when controller enable is set.
à Speed setting range 1 : 6 for Lenze
geared motors: For operation with
Lenze geared motors has to be set
necessarily.
C0011
uSEr
Maximum
output
frequency
50.00 7.50
à 87 Hz
{0.02 Hz} 650.00
C0012
uSEr
Acceleration
time main
setpoint
5.00 0.00 {0.02 s} 1300.00 Reference: frequency change 0 Hz ...
C0011
l Additional setpoint ðC0220
l Acceleration times that can be
activated via digital signals ð
C0101
C0013
uSEr
Deceleration
time main
setpoint
5.00 0.00 {0.02 s} 1300.00 Reference: frequency change C0011...
0 Hz
l Additional setpoint ðC0221
l Deceleration times that can be
activated via digital signals ð
C0103
C0014

Operating mode 2
2 V/f characteristic control V ~ f
(linear characteristic with constant V
min
boost)
l Commissioning is possible without
identifying motor parameters
l Advantage of identification with
C0148:
– Improved smooth running at low
speeds
– V/f rated frequency (C0015) and
slip (C0021) are calculated and
saved. They do not have to be
entered
3 V/f characteristic control V ~ f
2
(square−law characteristic with constant
V
min
boost)
4 Vector control
In the case of the first selection enter
the motor data and identify them
with C0148
Otherwise commissioning is not
possible
When C0014 = 5, C0019 must be set =
0 (automatic DC injection brake is
deactivated)
5 Sensorless torque control with speed
limitation
l Torque setpoint via C0412/6
l Speed limitation via setpoint 1
(NSET1−N1) if C0412/1 is assigned,
otherwise via maximum frequency
(C0011)
C0015
uSEr
V/f rated
frequency
50.00 7.50 {0.02 Hz} 960.00 l C0015 is calculated and saved
during the motor parameter
identification with C0148.
l The setting applies to all permitted
mains voltages
C0016
uSEr
V
min
boost
à
0.00 {0.01 %} 40.00 à device−dependent
Setting applies to all permitted mains
voltages

Lenze 8200 vector series Specifications

General

Category	DC Drives
Overload capacity	150% for 60 seconds
Protection class	IP20
Mains voltage	380V to 480V AC
Control method	Vector control
Communication options	CANopen
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Humidity	≤ 95% relative humidity, non-condensing
Series	8200 vector
