Commissioning
Important codes for quick commissioning
7
181
EDK82EV903 DE/EN/FR 5.1
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0034*
uSEr
Range of
setpoint
selection
Standard I/O
(X3/8)
Observe switch position of the
function module!
0
0 Unipolar voltage 0 ... 5 V / 0 ... 10 V
Current 0 ... 20 mA
1 Current 4 ... 20 mA Reversal of rotation direction only
possible with a digital signal.
2 Bipolar voltage −10 V ... +10 V l Minimum output frequency
(C0010) not effective
l Individually adjust offset and gain
3 Current 4 ... 20 mA open−circuit monitored TRIP Sd5 if I < 4 mA
Reversal of rotation direction only
possible with a digital signal.
C0034*
(A)
uSEr
Range of
setpoint
selection
Application I/O
Observe jumper position of the
function module!
1 X3/1U, X3/1I
0
0 Unipolar voltage 0 ... 5 V / 0 ... 10 V
2 X3/2U, X3/2I 1 Bipolar voltage −10 V ... +10 V Minimum output frequency (C0010)
not effective
2 Current 0 ... 20 mA
3 Current 4 ... 20 mA Reversal of rotation direction only
possible with a digital signal.
4 Current 4 ... 20 mA open−circuit monitored Reversal of rotation direction only
possible with a digital signal.
TRIP Sd5 at I < 4 mA
C0037 JOG1 20.00 −650.00 {0.02 Hz} 650.00
JOG = fixed setpoint
Additional fixed setpoints ðC0440
C0038 JOG2 30.00 −650.00 {0.02 Hz} 650.00
C0039 JOG3 40.00 −650.00 {0.02 Hz} 650.00
C0050*
uSEr
Output
frequency
(MCTRL1−NOUT)
−650.00 {Hz} 650.00 Read only: Output frequency without
slip compensation
C0087 Rated motor
speed
à
300 {1 rpm} 16000 à Device−dependent
C0088 Rated motor
current
à
0.0 0.1 (A) 650.0 à Device−dependent
0.0 ... 2.0 x rated output current of the
controller
C0089 Rated motor
frequency
50 10 {1 Hz} 960
C0090 Rated motor
voltage
à
50 {1 V} 500 à 230 V for 230 V controllers,
400 V for 400 V controllers
C0091 Motor cos
à
0.40 {0.1} 1.0 à Device−dependent
C0119
Configuration of
motor
temperature
monitoring (PTC
input) / earth
fault detection
0
0 PTC input inactive
Earth fault detection
active
l Configure signal output in C0415
l If several parameter sets are used,
monitoring has to be set
separately for every parameter set.
l Deactivate earth fault detection if
the earth fault detection is
actuated unintentionally.
l If the earth fault detection is
activated, the motor starts with a
delay of approx. 40 ms after
controller enable has been set.
1 PTC input active,
TRIP effected
2 PTC input active,
warning effected
3 PTC input inactive
Earth fault detection
inactive
4 PTC input active,
TRIP effected
5 PTC input active,
warning effected
