60
5. Mark the protocols to restrict based on the specified address range.
6. Click Save.
SNMP Configuration
Simple Network Management Protocol (SNMP) is a communication protocol designed
specifically for managing devices on a network. Equipment commonly managed with SNMP
includes switches, routers and host computers. SNMP is typically used to configure these
devices for proper operation in a network environment, as well as to monitor them to evaluate
performance or detect potential problems.
Managed devices supporting SNMP contain software, which runs locally on the device and is
referred to as an agent. A defined set of variables, known as managed objects, is maintained
by the SNMP agent and used to manage the device. These objects are defined in a
Management Information Base (MIB) that provides a standard presentation of the information
controlled by the agent. SNMP defines both the format of the MIB specifications and the
protocol used to access this information over the network.
The switch includes an onboard agent that supports SNMP versions 1, 2c, and 3. This agent
continuously monitors the status of the switch hardware, as well as the traffic passing through
its ports. A network management station can access this information using software such as
HP OpenView. Access to the onboard agent from clients using SNMP v1 and v2c is
controlled by community strings. To communicate with the switch, the management station
must first submit a valid community string for authentication.
Access to the switch using from clients using SNMPv3 provides additional security features
that cover message integrity, authentication, and encryption; as well as controlling user
access to specific areas of the MIB tree.
The SNMPv3 security structure consists of security models, with each model having it's own
security levels. There are three security models defined, SNMPv1, SNMPv2c, and SNMPv3.
Users are assigned to “groups” that are defined by a security model and specified security
levels. Each group also has a defined security access to set of MIB objects for reading and
writing, which are known as “views.” The switch has a default view (all MIB objects) and
default groups defined for security models v1 and v2c. The following table shows the security
models and levels available and the system default settings.
Table 7: SNMP Security Models and Levels
Model
Level
Community
String
Group
Read
View
Write
View
Security
v1
noAuth
NoPriv
public
default_
ro_group
default_vi
ew
none
Community string
only
