75
■ OutUcastPkts: The number of uni-cast packets that request to transmit.
■ OutNUcastPkts: The number of broad-cast and multi-cast packets that request to
transmit.
■ OutDiscards: The number of outbound packets that are discarded event the packets
is normal.
■ OutErrors: The number of outbound packets that could not be transmitted because of
errors.
■ OutQLen: The length of the output packet queue (in packets).
◆ Sample Type – The method of sampling the selected variable and calculating the value to
be compared against the thresholds, possible sample types are:
■ Absolute: Get the sample directly.
■ Delta: Calculate the difference between samples (default).
◆ Value – The value of the statistic during the last sampling period.
◆ Startup Alarm – The method of sampling the selected variable and calculating the value
to be compared against the thresholds, possible sample types are:
■ RisingTrigger alarm when the first value is larger than the rising threshold.
■ FallingTrigger alarm when the first value is less than the falling threshold.
■ RisingOrFallingTrigger alarm when the first value is larger than the rising threshold
or less than the falling threshold (default).
◆ Rising Threshold – Rising threshold value (-2147483648 ~ 2147483647).
◆ Rising Index – Rising event index (1-65535).
◆ Falling Threshold – Falling threshold value (-2147483648 ~ 2147483647).
◆ Falling Index – Falling event index (1-65535).
WEB INTERFACE
To configure RMON Alarm table:
1. Click Configuration, Security, Switch, RMON, Alarm.
2. Click Add New Entry to create a new entry. The entry index key is ID.
3. Specify the ID, Interval, Variable, Sample Type, Value, and other settings.
4. Click Save.
