Configuration the Simple Way Configure Inputs
Z-Max Advanced Programming & Systems Design Guide rac00-sdg
Revision A:11/2005 Page 31
• +SS indicating the specified hours:minutes after sunset
When done entering the time, press Select
Step 4: Enter the days of the week on which this event is to occur
• An uppercase day of the week indicates that the event will occur on that
day.
• A lowercase day of the week indicates that the event will not occur on that
day
• H1:ON indicates that the event will occur on any day which is part of the
holiday schedule #1
• H1:OFF indicates that the event will not occur on days which are part of
the specified holiday schedule
Step 5: Assign Relays
• Use or to increase or decrease the relay number
• Use to select any of the possible three
actions for this relay
• ON - turns this relay on when this event occurs
• OFF - turns the relay off when this event occurs
• IGNORE - instructs the relay panel to not change the state of this relay
when this event occurs
Step 6: Press Select/Save to save your changes.
SELECT DAYS
MTWTFSS H1:OFF
ASSIGN RELAYS
RELAY:001 ON
