17.11.3 Manipulation

NOTE Each stretcher can transport only single patient at a time and cannot be used to transport other items (except stretcher

accessories in secured position).

NOTE For information concerning uses other than those outlined in the “Specications of Use” section above, please contact

LINET ®.

Fig. Position of the i-Drive Power Main Control Panel on the IV&Drive

CAUTION!

Damage to i-Drive Power Main Control Panel cable due to wrong cable placement!

► Ensure that the main control panel connecting cable is placed correctly.

CAUTION!

Material damage due to incorrect use!

► Do not hang anything on the main control panel and its cable!
