D9U001ES2-0101_05
63
T
o lift Thighrest:
► grab Thighrest Handle, press
Thighrest Latch and lift Thighrest Handle with
Thighrest Latch until intended position is reached
► release the Thighrest Latch
T
o lower Thighrest:
► grab Thighrest Handle, press
Thighrest Latch and push Thighrest Handle with
Thighrest Latch down until intended position is
reached
► release the Thighrest Latch
14.3.2
Thighrest (only 4-part Mattress Support Platform)
62
64
