7.4 Environment Conditions of the Sprint 200

CAUTION!

Risk of damaging the product if its packaging is exposed to environmental conditions outside of those speci-

fied in the Environment Conditions of the Sprint 200 chapter!

WARNING!

Risk of damaging the product due to incorrect environment conditions!

► Do not use the Sprint 200 stretcher under the environmental conditions outside of those specified in

the Environment Conditions of the Sprint 200 chapter!

Parameter Value

Use Conditions

Ambient Temperature 10°C — 40°C

Relative Humidity 30% — 75 %

Atmospheric Pressure 795 — 1060 hPa

Storage and Transport Conditions

Ambient Temperature -20°C — 50°C

Relative Humidity 20% — 90 %

Atmospheric Pressure 795 — 1060 hPa
