17.4 Undercarriage Cover

Fig. Storage space (Undercarriage Cover of the Sprint 200 with i-Drive Power)

Fig. Storage space (Undercarriage Cover of the Sprint 200 without i-Drive Power)

CAUTION!

Risk of material damage due to objects on the undercarriage cover!

► Do not place objects on the undercarriage cover outside storage space!

► Respect dimensions of objects placed in storage spaces of the undercarriage cover during lifting, lowering

and tilting of the stretcher!

Longitudinal storage space (1) is intended for oxygen bottle (with capacity 10 litres (type E only), 5 litres or less). Suitable oxygen

bottle can be xed with quick-release strap.
