D9U001ES2-0101_0556
Fig. Manipulation with Collapsible Siderail
1. Siderail Handle
2. Siderail Release Lever
1
22
14.1.1 SIDERAIL DESCRIPTION
MANIPULATION
To raise siderail up:
► Grab siderail by Siderail Handle (1).
► Pull siderail up until it latches.
► Push siderail towards head end and foot end to ensure that siderail is secured in the upper position!
Red side parts of both Siderail Release Levers are not visible when the siderail is secured in the upper position.
Audible click is not the sucient indicator of the securely latched siderail!
To release siderail down:
► Unlock siderail by pulling Siderail Release Lever (2) at Foot End or at Head End.
► Fold down siderail slowly.
To facilitate unlocking the siderail if needed:
► Do not push the siderail towards stretcher head end when unlocking the siderail by the yellow Siderail Release Levers!
► Ensure no patient and no mattress push the siderail towards stretcher head end when unlocking the siderail by the yellow
Siderail Release Levers!
► Push the siderail slightly towards stretcher foot end to facilitate manipulation with the yellow Siderail Release Levers if
needed.
