D9U001ES2-0101_05
95
17.7 IV&Drive (Infusion Stands/Pushing Handles)
Fig. Pair of Foldable infusion stands (head end)
4
1
3
2
FOLD THE
MARKED
FOLDABLE
INFUSION
STAND AS
THE FIRST
ONE.
FOLD THE
MARKED
FOLDABLE
INFUSION
STAND AS
THE SECOND
ONE.
WARNING!
Risk of injury due to incorrect placement of an infusion pump!
► Ensure the infusion pump on the Foldable infusion stand will not collide with any movable parts of the Sprint
200 (especially Backrest) or with the patient!
CAUTION!
Risk of material damage due to incorrect placement of an infusion pump!
► Place an infusion pump carefully on the orange non-telescopic part of the Foldable infusion stand in order to
prevent the risk of injury or damage!
Foldable infusion stand equipped with 2 hooks is intended for carrying IV bags or baskets for intravenous solutions.
The pair of Foldable infusion stands can serve as handles for stretcher transport when they are raised.
It is possible to extend height of the Foldable infusion stand and to fold down the Foldable infusion stand again.
Pair of the Foldable infusion stands is located in corners of head end or foot end.
Maximum load of one hook is 5 kg.
The pair of Foldable infusion stands can be equipped with i-Drive Power Control Panel.
