CBX 500 Multiservice WAN Switch Hardware Installation Guide 4/5/03Index-3
Index
H
Hardware
front and back view, A-9
Hardware components, 1-4
Hardware specifications, 2-1 to 2-4
Hot swapping SP modules. See SP module
I
I/O adapter modules. See IOA modules
I/O adapters (IOAs)
cable requirements, A-8
front and back view, A-9
installing, 6-14, 6-16, 6-21, 6-22
I/O processor (IOP)
diagram, IMA IOM, A-48
I/O processor modules. See IOP modules
I/O processors (IOPs)
front and back view, A-9
installing, 6-14, 6-16, 6-21, 6-22
Installation
completing, 5-9, 5-11
considerations, 6-2
preparing for, 4-2
prerequisites, 4-1
site selection, 3-1
Installing the module
cable requirements, A-8
Interfaces, physical, A-7
International Telecommunication Union
(ITU)
standards supported, A-7
IOA modules
configuring for redundancy, D-3
description, 1-9
installing, 6-22
replacing, 6-22
IOP modules
4-port channelized DS3 Frame/IP, A-20
configuring for redundancy, D-3
description, 1-8
determining operating status of, 5-2
DIP switch settings, 7-2
installing, 6-18
replacing, 6-18
ITU. See International Telecommunication
Union
K
Keep-alive
mechanism, D-6, D-7
poll counter, D-6
poll timer, D-6
poll verification counter, D-6
poll verification finder, D-6
L
LEDs
DC power failure status, 5-6
IOP module, 7-4
module status, 5-3
PCMCIA status, 5-5
power supply, 7-5
power supply status, 5-5
redundancy status, 5-4
switch status, 7-3
