363-206-285 Circuit Order: NTP-010
Issue 2, February 2000 Page 4 of 8
DDM-2000 OC-3 MULTIPLEXER
DO ITEMS BELOW IN ORDER LISTED . . . . .FOR DETAILS, GO TO
9.
NOTE:
Standard DS1 transmitter sources are designed to terminate
in a nominal 100-ohm impedance. This termination is usually
provided by the receiving equipment. When not connected to
receiving equipment (that is, idle or unterminated), DS1
transmitter equipment should terminate in a 100-ohm load.
When connecting through DSX equipment, this can be
accomplished with terminating plugs available from the DSX
manufacturer. Any alternative method may be used resulting
in 100-ohms across the TIP and RING of the DS1 circuit
output while in an idle state. Failure to terminate DS1 outputs
may result in violation of FCC Part 15 emission requirements
and possibly interfere with other electronic equipment. Also,
AIS should be turned off (using the
set-t1:address:ais=no command) on any DS1 circuit
that is not in service.
NOTE:
If the group is to be equipped with any BBF3/BBF3B
DS1PM circuit packs, both service and protection MXRVO
circuit packs must be installed.
DLP-506Install MXRVO circuit packs into proper slots of FUNCTION
UNITS group (A, B,orC) being converted to DS1 service.
DLP-50810. Option and install required service DS1/DS1PM circuit packs.
11.
NOTE:
If DS1 protection is required and service DS1PM circuit
packs are installed, a DS1PM circuit pack must be installed
in the protection 8(P) slot.
DLP-508Install protection DS1/DS1PM circuit pack into slot 8(P) of group
being put into service, if required.
12. Use the set-t1: command to set the characteristics of the DS1
port.
DLP-506
DLP-508
To Next Page
