Lucent Technologies DDM-2000 OC-3 User Manual

NTP-039: Circuit Order 363-206-285
Page 10 of 32 Issue 2, February 2000
DDM-2000 OC-3 MULTIPLEXER
DO ITEMS BELOW IN ORDER LISTED. . . . . FOR DETAILS, GO TO
15. At Node 1, remove optical fiber from OLIU MAIN 2(P) OUT and
connect it to the other output of the optical splitter. (See Figure 5.)
Figure 5 – DDM-2000 OC-3 Drop or Add/Drop Network to Ring Upgrade
