NTP-058: Circuit Order 363-206-285
Page5of6 Issue3,June2001
DDM-2000 OC-3 MULTIPLEXER
DO ITEMS BELOW IN ORDER LISTED. . . . . FOR DETAILS, GO TO
14. Enter the update (upd) command using the CIT. If the MAIN 1
update is successful, you will see the following message:
main-2 OLIU not updated - no change in provisioning
The FAULT LED on the 29-type OLIU in MAIN 1 will initially be lit
but should extinguish. This may take up to 5 minutes. The FAULT
LED on MAIN 2(P) OLIU will light. Perform a rtrv-alm and
verify that only a minor alarm “main-2 CP not allowed” is present.
Remotely log in to the connected node and verify that only VT AIS
and/or STS AIS alarms are present. If the update is successful,
proceed to Step 14.
If the MAIN 1 update fails, you will see the message:
main-1 OLIU not updated - OC12 upgrade aborted
followed by one or more descriptive messages indicating the
reason for the failure.
• A “Line Fault” message indicates that the shelf has detected
a degradation of the incoming OC-12 optical signal. Verify the
optical input level and fiber connections and far-end OLIU
before attempting the upgrade procedure again.
• A “Pack Failure” message indicates a problem with the pack.
The upgrade procedure should be re-attempted with a
different 29-type OLIU.
NOTE:
A CP removed alarm will occur in this step when the MAIN
2(P) OLIU is removed. A inc. OC-12 LOS alarm will occur at
the connecting Node.
15. At the starting node, remove optical fibers from MAIN 2(P) OLIU
and lift the faceplate latch, then remove MAIN 2(P) OLIU.
To Next Page
