363-206-285 Trouble Clearing: TAP-107
Issue 2, February 2000 Page 20 of 28
DDM-2000 OC-3 MULTIPLEXER
inc. OC12 LOF CR or MN The system has detected a loss-of-frame (LOF)
condition in an incoming OC-12 signal. LOF is
defined as an out-of-frame (OOF) condition (five
consecutive errored STS-1 framing patterns) that
lasts for at least 3 milliseconds.
Likely causes: Failure of the OLIU circuit pack at
the near end, failure of the OLIU circuit pack at the
far end, or failure of the receive fiber.
inc. OC12 LOS CR or MN The system has detected loss-of-signal (LOS)
condition on the OC-12 line.
Likely causes: Failure of the OLIU circuit pack at
near end, failure of the OLIU circuit pack at far end,
or failure of the receive fiber.
inc. OC12 line AIS CR, MJ,
MN, or
None
The system has detected OC-12 line alarm
indication signal (AIS) on an incoming OC-12 line.
Likely cause: Failure of an OLIU circuitpackatthe
far end.
inc. OC12 sig degrade (BER) CR or MN The bit error ratio (BER) in the specified OC-12
line exceeds the provisioned soft error threshold
(10
–9
to 10
–5
) but below the hard error threshold of
10
–3
.
Likely causes: Failure of the OLIU circuit pack at
the near end, failure of the OLIU circuit pack at the
far end, failure of the receive fiber, or incorrect
setting of the optical power switch on the OLIU
circuit pack.
inc. OC12 sig failed (BER) CR or MN The bit error ratio (BER) in the specified OC-12
signal exceeds 10
–3
.
Likely causes: Failure of the OLIU circuit pack at
the near end, failure of the OLIU circuit pack at the
far end, or failure of the receive fiber.
inc. STS1 AIS CR, MJ,
MN, or
None
The system has detected an incoming STS-1 alarm
indication signal (AIS) in the active OC-3, OC-12,
or OC-1 line. The system responds by transmitting
DS1 or DS3 AIS toward the DSX and transmitting
STS-1 yellow toward the fiber from which the AIS is
being received.
Likely causes: Incomplete or incorrect
cross-connect provisioning in an end-to-end
network. Unprotected removal or failure of a DS3,
MXRVO,orOLIU circuit pack at the far end, or
unprotected optical line failure.
Table B – RTRV-ALM Message Descriptions (Continued)
Description
Alarm
Level Meaning
To Next Page
