363-206-285 Detailed Level Procedure: DLP-504
Issue 2, February 2000 Page 2 of 4
DDM-2000 OC-3 MULTIPLEXER
NOTE:
In a Stand-Alone DDM-2000 OC-1 ring application, the DDM-2000 OC-3
FiberReach host requires 26G2-U, 27G-U or 27G2-U OLIUs be installed
in the MAIN slots. The single-homed DDM-2000 OC-3/FiberReach ring
configuration requires that the FUNCTION UNITS-( )-1 OLIU on the
OC-3 host shelf connect to the MAIN-1 OLIU at the first FiberReach shelf
from the OC-3 host shelf. MAIN-2 OLIU at an adjacent FiberReach shelf
(node) connects to the MAIN-1 OLIU at an adjacent FiberReach shelf
(node). The MAIN-2 OLIU at the last FiberReach shelf on the OC-1 ring
connects to FUNCTION UNITS-( )-2(P) OLIU on the OC-3 host shelf.
NOTE:
A dual-homed ring configuration requires that the first FiberReach
MAIN-1 OLIU connect to FUNCTION UNITS-( )-1 OLIU on one host
OC-3 shelf. The last FiberReach MAIN-2 OLIU connects to the
FUNCTION UNITS-( )-2(P) OLIU on the other OC-3 host shelf.
Intermediate FiberReach shelves on the same OC-1 ring connect from
MAIN-2 OLIU at one FiberReach shelf to the MAIN-1 OLIU at an
adjacent FiberReach shelf (node).
NOTE:
The DDM-2000 OC-3 shelf OC-12 ring application requires 24G-U/24H-U
or 29G-U/29H-U OLIUsbeinstalledintheMAIN slots.
Install OLIU into required MAIN 1 or FUNCTION UNITS-( )-1 slot.
Response: FAULT LED and ACTIVE LED lights. FAULT LED begins
flashing after about 10 seconds.
[OHCTL FAULT LED may begin flashing if far-end
communications (fecom) is enabled.]
Comment: Critical, major or minor alarm LEDs light depending on the
version of software installed. Generally, the MJ (fecom
enabled) or MN (fecom disabled) LED will light for ring
releases.
To Next Page
