363-206-285 Detailed Level Procedure: DLP-507

Issue 2, February 2000 Page 3 of 4

DDM-2000 OC-3 MULTIPLEXER

4. Are you installing BBG4/BBG4B DS3/BBG20 TMUX circuit packs or BBG19

DS3 circuit packs?

If BBG4/BBG4B/BBG20, continue with Step 5.

If BBG19, proceed to Step 9.

NOTE:

If the response is not correct in the following procedures, replace the

DS3/TMUX circuit pack.

Seat a DS3/TMUX circuit pack in FUNCTION UNITS group slot A-1, B-1,or

C-1.

Response: FAULT LED on the DS3/TMUX lights for about 20

seconds then goes off. ACTIVE LED lights on the first

DS3/TMUX circuit pack of the pair installed.

6. If required, seat a second (protection) DS3/TMUX circuit pack in FUNCTION

UNITS group slot A-2(P), B-2(P),orC-2(P) of the same FUNCTION UNITS

group.

Response: FAULT LED on the DS3/TMUX lights for about 20

seconds then goes off. ACTIVE LED remains off.

7. Repeat this procedure from Step 1 for each pair of DS3/TMUX circuit packs to

be installed.

8. STOP. YOU HAVE COMPLETED THIS PROCEDURE.
