Lucent Technologies DDM-2000 OC-3 User Manual

363-206-285 Detailed Level Procedure: DLP-514
Issue 2, February 2000 Page 14 of 18
DDM-2000 OC-3 MULTIPLEXER
Table H – DDM-2000 OC-3 Shelf to OC-12 Shelf OC-12 Measured Optical
Power and Required LBO
Transmitter
Receiver
24G-U/24H-U OLIU
29G-U/29H-U OLIU
(OC-3 Shelf With
OC-12 Optics)
23G/23G-U OLIU
(OC-12 Shelf)
23H/23H-U OLIU
(OC-12 Shelf)
Received
Power(dBm)
LBO
(dB)
Received
Power(dBm)
LBO
(dB)
Received
Power(dBm)
LBO
(dB)
24G-U/24H-U OLIU
29G-U/29H-U OLIU
(OC-3 Shelf With
OC-12 Optics)
2.0 to –3.0 20
2.0 to 1.0 15 2.0 to 1.0 15 –3.0 to –8.0 15
1.0 to –4.0 10 1.0 to –4.0 10 –8.0 to –13.0 10
–4.0 to –9.0 5 –4.0 to –9.0 5 –13.0 to –18.0 5
–9.0 to –31.0 0 –9.0 to –31.0 0 –18.0 to –34.0 0
23G/23G-U OLIU
(OC-12 Shel
f)
2.0 to –3.0 20
2.0 to 1.0 15 2.0 to 1.0 15 –3.0 to –8.0 15
1.0 to –4.0 10 1.0 to –4.0 10 –8.0 to –13.0 10
–4.0 to –9.0 5 –4.0 to –9.0 5 –13.0 to –18.0 5
–9.0 to –31.0 0 –9.0 to –31.0 0 –18.0 to –34.0 0
23H/23H-U OLIU
(OC-12 Shelf)
2.0 to –3.0 20
2.0 to 1.0 15 2.0 to 1.0 15 –3.0 to –8.0 15
1.0 to –4.0 10 1.0 to –4.0 10 –8.0 to –13.0 10
–4.0 to –9.0 5 –4.0 to –9.0 5 –13.0 to –18.0 5
–9.0 to –31.0 0 –9.0 to –31.0 0 –18.0 to –34.0 0
Notes:
1. Measured power is defined to be the measured power of the light emitted from receive fiber connector at OLIU.
2. The minimum measured received power allows for optical path penalty and unallocated margin. Connector loss is
not allotted for; it should already be accounted for in the optical power measurement.
3. The margin for falling within the max rx power is 1.0 dB.
Table I – In-Line Single-Mode (SM) and Multimode (MM) Lightguide
Buildouts
Lightguide
Buildout (LBO) Code Comcode
Connector
Type
Fiber
Connection
Label
Color
5 dB A2000B 106597297
ST MM-MM Blue
10 dB A2000D 106597446
ST MM-MM Black
5 dB A3000B 106060718
ST SM-SM Blue
10 dB A3000D 106060734
ST SM-SM Black
