Lucent Technologies DDM-2000 OC-3 User Manual

DLP-514: Detailed Level Procedure 363-206-285
Page 15 of 18 Issue 2, February 2000
DDM-2000 OC-3 MULTIPLEXER
Table J – Universal Single-Mode (SM) ST
®
Lightguide Buildouts
Lightguide
Buildout (LBO) Code Comcode
Connector
Type
Fiber
Connection
Label
Color
0 dB A3070 106795354
ST SM-SM & MM-MM None
5 dB A3070B1 107406183
ST SM-SM Blue
10 dB A3070D1 107406191
ST SM-SM Black
15 dB A3070F1 107406209
ST SM-SM Green
Table K – Universal Single-Mode (SM) FCPC Lightguide Buildouts
Lightguide
Buildout (LBO) Code Comcode
Connector
Type
Fiber
Connection
Label
Color
0 dB A3080 106795404 FC SM-SM & MM-MM None
5 dB A3080B1 107406225 FC SM-SM Blue
10 dB A3080D1 107406233 FC SM-SM Black
15 dB A3080F1 107406241 FC SM-SM Green
Table L – Universal Single-Mode (SM) SC Lightguide Buildouts
Lightguide
Buildout (LBO) Code Comcode
Connector
Type Fiber Connection
Label
Color
0 dB A3060 106708951 SC SM-SM & MM-MM None
5 dB A3060B1 107406142 SC SM-SM Blue
10 dB A3060D1 107406159 SC SM-SM Black
15 dB A3060F1 107406167 SC SM-SM Green
Table M – Universal Multimode (MM) ST
®
Lightguide Buildouts
Lightguide
Buildout (LBO) Code Comcode
Connector
Type
Fiber
Connection
Label
Color
5 dB A2070B 106795313 ST MM-MM Blue
10 dB A2070D 106795321 ST MM-MM Black
15 dB A2070F 106795339 ST MM-MM Green
Table N – Universal Multimode (MM) SC Lightguide Buildouts
Lightguide
Buildout (LBO) Code Comcode
Connector
Type
Fiber
Connection
Label
Color
5 dB A2060B 106795271 SC MM-MM Blue
10 dB A2060D 106795289 SC MM-MM Black
15 dB A2060F 106795297 SC MM-MM Green
