363-206-285 Detailed Level Procedure: DLP-528
Issue 2, February 2000 Page 9 of 12
DDM-2000 OC-3 MULTIPLEXER
30.
NOTE:
If floppies are being used, ensure the first (number 1) diskette is installed
in floppy drive. If hard drive is being used, ensure you are in the correct
directory.
Enter the command ins-prog:tid
Where tid = the target identifier (shelf name) for the far-end
DDM-2000 shelf having the new program installed.
Response: /* Testing For IMA LAN Program
Installation... */
After several seconds, the PC prints a Caution!
message followed by the prompt:
Execute? y/n =.
31. Was response correct?
If YES, then continue with Step 32.
If NO, then do Trouble Clearing: TAP-122.
32. Enter a y or yes and a carriage return to execute the program. Software
download may take up to 5 minutes.
Response: ABN LED lights on User Panel. A "P." is displayed in
SYSCTL FE ID display in the far-end shelf receiving the
program (for uncompressed executingcopy download, not
if dormant copy is being loaded). PC starts download and
prints the following message:
Searching for optimal transfer rate.
Handshake established at <baudrate> baud.
In progress....
The dots continue to print until program installation is
complete. If floppy disks are being used, insert each
diskette when prompted. After installation is completed,
the PC prints the following completion message:
lan ins-prog:TID COMPLD
/* IMA LAN Generic program a.b.c is
installed */
The SYSCTL resets, and the terminal is logged off the
system. The LEDs go off on the User Panel and SYSCTL.
TAP-122
