363-206-285 Detailed Level Procedure: DLP-537
Issue 2, February 2000 Page 3 of 6
DDM-2000 OC-3 MULTIPLEXER
12. Is fuse(s) blown?
If YES, then continue with Step 13.
If NO, then proceed to Step 14.
13. Replace fuse(s) and repeat from Step 5.
14.
NOTE:
Test set may be used for testing using one, two, three, or all four BATT
plug positions.
There is a defective test set or connector head. Note defective BATT plug
position(s). Continue with test procedures using remaining BATT plugs.
15. Does test set TIME display indicate 00 MIN:00 SEC without blinking?
If YES, then continue with Step 16.
If NO, then proceed to Step 35.
16. Does status display indicate which battery was connected, status (GOOD or
REPLACE) of the battery, and is READY indicator lighted?
If YES, then continue with Step 17.
If NO, then proceed to Step 35.
17. Does status display indicate GOOD or REPLACE?
If YES, then proceed to Step 19.
If NO, then continue with Step 18.
18.
!
DANGER:
A high discharge current is present at connector head if TESTING
indicator is lighted. Batteries must not be connected or disconnected
when TESTING indicator is lighted.
Battery pack is defective. Ensure that TESTING indicator is not lighted
(READY indicator lighted), unplug and set aside defective battery pack, and
repeat from Step 5.
19. Have TIME display and STATUS indicators been tested for each good BATT
plug position?
If YES, then proceed to Step 21.
If NO, then continue with Step 20.
