Lucent Technologies DDM-2000 OC-3 User Manual

363-206-285 Detailed Level Procedure: DLP-551
Issue 2, February 2000 Page 1 of 4
DDM-2000 OC-3 MULTIPLEXER
Replace DDM-2000 OC-3 Shelf User Panel
OutofService
1.
!
CAUTION:
For an in-service shelf, it will be necessary to remove service prior to
performing this procedure.
NOTE:
The ED-8C724-31, G1 User Panel in the ED-8C724-30, G1 DDM-2000
OC-3 Shelf can not be replaced in the field.
NOTE:
This procedure provides instructions for replacement of the User Panel in
an ED-8C724-30, G3 or G4 DDM-2000 OC-3 Shelf.
Tools, Accessories, and Material
The following is required:
Preparation
2. If the shelf is in service, verify that the shelf is free of alarms and that no
protection switches are active. Remove service from the shelf.
Table A – Tools, Accessories, and Material
Quantity Description
1
ED-8C724-31, G2 or G3 User Panel
1
Screwdriver
1
Pliars
1
Wrist Strap
*
* A grounded wrist strap must be worn when
handling circuit packs
