Tables
Issue 3 June 2001 xxv
3 Shelf Descriptions and Configurations
3-1 DDM-2000 OC-3 Plug-Ins 3-4
3-2 DDM-2000 OC-3 Multiplexer Circuit Pack and
Software Compatibility Matrix 3-10
3-3 DDM-2000 Fan Shelf Switch Settings 3-27
5 Transmission and Synchronization Interfaces
5-1 DDM-2000 OC-3 Multiplexer Transmission
Interfaces 5-1
5-2 DDM-2000 OC-3 Synchronization 5-34
5-3 Synchronization Messages using K2 Byte 5-39
5-4 Synchronization Messages using S1 Byte * 5-40
5-5 Available Synchronization References 5-41
6 Operations Interfaces
6-1 Craft Interface Terminals 6-3
6-2 DDM-2000 OC-3 Pushbutton Combinations 6-11
7 Circuit Pack Descriptions
7-1 HDSL Line Specifications 7-47
7-2 DDM-2000 OLIU Feature Summary 7-101
7-3 29G-U/29H-U OLIU Specifications 7-152
7-4 29G-U/29H-U OLIU Link Budgets (Notes) 7-153
7-5 Performance Monitoring Parameters Provisionable
via the CIT 7-155
8 Administration and Provisioning
8-2 Default DS1 to VT1.5 Mapping 8-10
8-3 OI Software Compatibility 8-17
8-8 Ring STS-1 Cross-Connections (Termination/Drop)
(Note) 8-34
