Lucent Technologies DDM-2000 OC-3 User Manual

DLP-562: Detailed Level Procedure 363-206-285
Page 2 of 12 Issue 2, February 2000
DDM-2000 OC-3 MULTIPLEXER
4.
!
CAUTION:
TIMING slot 2 should always be equipped with a TGS/TG3 circuit pack
and be active prior to software download. To clear a " C " condition from
the
SYSCTL FE ID display, procedures will require removal of the
TGS/TG3 circuit pack from TIMING slot 1 to force the system to run the
new software. See Table A.
NOTE:
If a linear shelf is in the STS3c mode (concat mode enabled by the
set-oc3: command) and a different software generic that does not
have the STS3c feature is loaded, the OLIUs will stay in the concat
mode until they are removed and reseated.
Table A – DDM-2000 OC-3 Inservice Software Upgrade Compatibility (Note)
Current Release
Upgrade to
*
* When doing an upgrade, it is recommended that the latest
point release of software be used, if possible.
13.0 15.0
7.1.n (Ring)
C
†
† Incompatible OSI stack requires special considerations. See
824-102-144,
Lucent Technologies 2000 Product Family,
Operations Interworking Guide For TARP Releases
for
special considerations.
C
†
7.2.n (Ring)
C
†
C
†
8.0.n (Linear)
C
†
C
†
8.1.n (Linear)
C
†
C
†
9.0.n (Ring)
U
†
U
†
9.1.n (Ring)
X
†
X
†
11.0.n (Ring)
X
†
X
†
13.0.n (Ring) X X
15.0.n (Ring) X X
Note: All DDM-2000 OC-3 shelves in a subnetwork should
be using TARP Release 13.0 or 15.0 software.
U Requires local software download only to upgrade the
system.
X Requires local or remote software download only to
upgrade the system.
C Requires an upgrade procedure with on-site
equipment/fiber changes as well as software download to
upgrade the system. Additional changes to software and
equipment provisioning may be needed to use features of
the new release.
