Lucent Technologies DDM-2000 OC-3 User Manual

363-206-285
Commands and Reports
11-4
Issue 2 February 2000
Table 11-1. DDM-2000 OC-3 Address Table
Object Entity Address Example
Entire System all all
Main slot main-{1,2,all} main-all
Function unit slot fn-all
fn-{a,b,c}-{1,2,all}
fn-all
fn-b-all
fn-c-all
Slots
Function unit pair fn-{a,b,c} fn-a
Low speed slot ls-all
ls-{a,b,c}-{1-8,all}
ls-all
ls-b-2
Timin
g
slot tg-{1,2,all} tg-all
Sys. control slot sysctl sysctl
Aux. control slot auxctl auxctl
OC-3 line pair all
main, fn-{a,b,c,all}
all
main-1
OC-3 line all
main-{1,2,all}, fn-{a,b,c,all}-{1,2,all}
fn-all
all
main-1
fn-c-2
fn-all
Lines
OC-1 line pair
(27-type OLIU)
all
main-all
main-{1,2,all}
fn-all
fn-{a,b,c}-{1,2,all}
all
main-all
main-2
fn-all
fn-a-all
fn-b-2
OC-1 line
(27-type OLIU)
all
main-all
main-{1,2}-{1,2}
fn-all
fn-{a,b,c}-all
fn-{a,b,c}-{1,2}-{1,2}*
all
main-all
main-2-2
fn-all
fn-b-all
fn-a-2-2
OC-12 line pair all
main
all
main
OC-12 line all
main-{1,2,all}
all
main-2
EC-1 line a,b,c,all c
* For OC-1 line addresses, the address is configured as {func. unit}-[slot}-{line in slot}.
(Table continues on the following page)
