Commands and Reports
Issue 2 February 2000
11-5
Table 11-1. DDM-2000 OC-3 Address Table
Object Entity Address Example
DS-3 (BBG4 or BBG4B
only), EC-1 port, or
TMUX (BBG20) port
a,b,c,all a
Front-Access DS3
(BBG19) Port
{a,b,c,all*}-{1-2,all} a-1
Ports
DS1 port (including
TMUX)
{a,b,c,all*}-{1-7,all}-{1-4,all} all
b-all
b-2-all
c-1-4
DS1 sync. ref. port ref-{1,2} ref-1
STS-1 channel
(within OC-3)
{m,c,all*}-{1-3,all}, {a,b}-{1,2,all}
m{1,2}-{1-3,all} (Rings Only)
c-3
a-2
m2-3
STS-1 channel (within
OC-12 using 24G-U or
29G-U OLIUs in Main)
m{1,2}-{1-12,all} (Rings Only) m2-7
STS-1 channel (within
OC-1 using 27-type
OLIUs)
all
{m,a,b,c}{1,2}-{1-2,all}
all
m2-2
STS-1 channel for DS3,
MXRVO, STS1E, TMUX
a,b,c,all a
STS-3c channel (within
OC-12 using 24G-U or
29G-U OLIUs in Main)
m{1,2}-{1,4,7,10,all} (Rings) m1-1
Channels
VT1.5 channel
(within OC-3)
{m,c,all*}-{1-3,all*}-{1-7,all*}-{1-4,all}
{a,b,all*}-{1,2,all*}-{1-7,all*}-{1-4,all}
m{1,2}-{1-3,all*}-{1-7,all*}-{1-4,all} (RingsOnly)
c-1-2-1
b-2-7-4
m1-3-2-3
VT1.5 channel (within
OC-12 using 24G-U
OLIUs)
m{1,2}-{1-12,all*}-{1-7,all*}-{1-4,all} (Rings) m1-7-4-3
VT1.5 channel for DS1,
STS1E, or TMUX
{a,b,c,all*}-{1-7,all*}-{1-4,all} a-1-2
b-7-4
VT1.5 channel (within
OC-1 using 27-type
OLIUs)
all
{m,a,b,c}{1,2}-all
{m,a,b,c}{1,2}-{1,2}-all
{m,a,b,c}{1,2}-{1,2}-{1-7}-{1-4,all}
all
b1-all
c2-2-all
c2-1-7-4
* If
all
is chosen as any part of an address, no subsequent address fields should be defined.
(Table continues on the following page)
