6.5 USE OF FUEL AND LUBRICATING OIL M A E D A Crawler Crane
6-12 5/2020 CC1908S-1
Note 3: Fuel
(1) Use fuel that complies with the following standards.
Diesel fuel standards Region
JIS K 2204 Grade 1 to 3 Japan
SAE D975
No. 1D S15
No. 2D S15
USA
EN 590:96 EU
ISO 8217 DMX International standard
BS 2869-A1 (or A2) UK
KSM-2610 Republic of Korea
GB252 China
(2) If using biofuel, use fuel that complies with one of the following standards.
• EN 14214, EN 590
• ASTM D6751, D7467
• JIS K 2390
(3) The fuel used must comply with the following standards and restrictions.
• Do not use fuel with a sulphur content exceeding 15 ppm (mass).
• Do not use fuel containing zinc or sodium.
• Do not use paraffin.
• Do not mix paraffin with the fuel.
• Do not use fuel that has been stored for extended periods in drums.
• Do not use fuel purchased from unapproved retailers.
Oil/fuel chart
Lubrication area Specified oil quantity (L) Replacement oil quantity (L)
Engine oil 11.6 10.5
Hydraulic oil system 225 110
Travelling motor gearbox casing (right) 4.7 4.7
Travelling motor gearbox casing (left) 4.7 4.7
Winch motor gearbox casing 1.7 1.7
Cooling system 15.5 ---
Fuel tank 150 ---
Washer tank
3.3 ---
