M A E D A Mini-Crawler Crane Section 4 – REMOTE CONTROL SYSTEM INTRODUCTION
3/2019 MC305C-3 4-75
REMOTE CONTROL
SYSTEM INTRODUCTION
This section describes the remote control
operating procedures. Before you perform any
remote control operating procedures, read
"Section 2 SAFETY".
General
No Modification
WARNING! Do not attempt to modify or
disassemble the Transmitter and Receiver,
or the accessories, which may cause an
electrical shock or a fire.
Fig. 4-202
Fig. 4-203
Holding the Transmitter
WARNING!
• The Transmitter is designed for one hand
controls in general.
Refer to the figure for basic usage of the
Transmitter.
Levers and buttons can be manipulated by
the thumb, while the Accelerator lever can
be triggered by the forefinger.
Other fingers should grab the grip to hold
the Transmitter.
• Always manipulate levers and switches by
fingers.
Do not attempt to pick them by a sharp
edge or such for manipulation.
It may make an opening in the Transmitter
which allows water to enter inside and
brings its troubles or failures and cause a
serious hazard.
Fig. 4-204
Fig. 4-205
No Water Washing
WARNING!
• Always keep the Transmitter unsoiled, and
clean it when necessary. Oil or mud on
surface may cause mis-operation by
slipping hands, which may result a serious
hazard.
• Do not attempt water-wash the Transmitter,
in any event.
It allows water to enter inside and brings
its troubles or failures and cause a serious
hazard.
• Scrub the Transmitter and Receiver with a
wet cloth from water or diluted detergent to
remove the dart.
Avoid alkaline or alcoholic cleaners or
sprayer cleaners which deteriorate plastics
and produce cracks.
