Section 4 –
TRAVELLING CONTROLS AND OPERATION Mini-Crawler Crane M A E D A
4-22 3/2019 MC305C-3
Allowable Water Depth
Use this machine in the water of the depth of
under the centre of the idler (1) where the muffler
beneath the machine body doesn’t go under
water.
Fig. 4-53
Cautions on Upward/Downward
Slope
WARNING!
• If the machine tilts for "15 degrees" or
more forward, backward, leftward, or
rightward while travelling, the machine
may overturn. Do not travel on the slope of
more inclination.
• Be sure to switch the travelling high-speed
switch to the "OFF" (low speed) position
when travelling on the slope.
• Travelling on the slope in the high-speed
travelling mode may result in overrun on
the downward slope.
• The slopes inclined for 15 degrees or more
presents overturning hazard. Do not travel on
these slopes.
• Be sure to switch the travelling high-speed
switch to the "OFF" (low speed) position when
travelling on the slope. The machine may
overrun.
• Never change the direction on the slope or cut
the slope horizontally.
Fig. 4-54
• Travel safely such as by going down to the
level ground and taking a detour.
• Operate the acceleration pedal and travelling
levers to decrease the travelling speed as
much as possible when going down the slope.
• Operating the travelling lever to the "Neutral"
position automatically brakes the machine, but
may overrun when going down the slope at
high speed.
• Direct the machine perpendicular to the slope
and the operation seat must be the side of the
uphill when travelling on the slope.
Fig. 4-55
• If the engine stops on the slope, return the
travelling levers to the "Neutral" position and
start the engine.
To Next Page
